020460Y Scooter diagnosis and tester
020330Y Stroboscopic light for timing control
Proceed as follows:
- Remove the outside transmission cover as de-
scribed in the automatic transmission chapter.
- Remove the TDC reference inspection cap be-
tween flywheel and crankcase cover. See the fly-
wheel cover chapter.
- By the driving pulley, turn the engine to find the
alignment of the references to identify the TDC.
- Repeat for the reference between driving pulley
and transmission housing.
Engine MP3 400 i.e.
ENG - 76
