PIAGGIO MP3 400 i.e. - Fuel tank

Headlight assy.
Fuel tank
Remove the chassis central cover.
Remove the footrest.
Remove the three tank retainers.
Remove the two lower bracket retainers indicated
in the figure.
Disconnect the electric wiring and the fuel pipes.
See also
Footrest
MP3 400 i.e. Chassis
CHAS - 13
