Select the POTENTIOMETER RESET option from
the SYSTEM RESET menu and press OK.
WAIT....
PROCEDURE IN PROGRESS
The hand-held computer displays the words:
CHECK THAT THE CONTROL IS SET AT 12°
FROM THE LOWER STOP. PRESS OK TO CON-
TINUE
Press OK
The hand-held computer displays the words: POS-
SIBLE LIMIT STOP VALUES. PRESS A KEY AND
SHIFT OFF AND ON
If this is not successful, the tilt locking mechanism
remains locked for safety.
Adjust the flexible transmission so that a small
clearance is left to guarantee switch activation on
the tilt locking calliper
Remove the two bracket screws after releasing the
spring and freeing the flexible transmission adjust-
ment.
CAUTION: A FIRST PRODUCTION BATCH WILL
BE EQUIPPED WITH DOUBLE COAXIAL
SPRING.
It is very important to remove the flexible trans-
mission from its fitting only for replacement.
MP3 400 i.e. Suspensions
SUSP - 19
