020376Y Adaptor handle
Remove the spring/toothed sector unit from its fit-
ting, slightly hit with a mallet if necessary to release
the unit.
Extract the bearing of the spring/toothed sector
unit with the specific tool.
Specific tooling
001467Y002 Driver for OD 73 mm bearing
Extract the bearing of the electric motor with the
specific tool.
Hold the crankcase in a perfectly horizontal posi-
tion, heat it with a heat gun at a temperature of
about 120 °C, use the specific tool to fit the bearing
of the spring/toothed sector unit. Hit slightly with a
mallet if necessary.
Specific tooling
020360Y Adaptor 52 x 55 mm
020151Y Air heater
020376Y Adaptor handle
MP3 400 i.e. Suspensions
SUSP - 25
