User manual - ATR244 - 21
Modbus
address
Description
Read
Write
Reset
value
1010
Error flags 2
Bit0 = Missing calibrations error
Bit1 = Eeprom CPU bench parameters corrupted
Bit2 = Eeprom CPU setpoint bench corrupted
Bit3 = RFid memory not formatted
Bit4 = Error AI2 disabled
RO 0
1011
Digital inputs status (0=not active, 1=active)
Bit0 = Digital inp. 1 Bit2 = Digital inp. 3
Bit1 = Digital inp. 2 Bit3 = Digital inp. 4
RO 0
1012
Outputs status (0=off, 1=on)
Bit 0 = Q1 Bit 3 = DO1
Bit 1 = Q2 Bit 4 = DO2
Bit 2 = Q3
RO 0
1013
Stato led (0=OFF, 1=ON)
Bit 0 = Led UP arrow Bit 6 = Led TUN
Bit 1 = Led C1 Bit 7 = Led point time 2
Bit 2 = Led C2 Bit 8 = Led MAN
Bit 3 = Led A1 Bit 9 = Led REM
Bit 4 = Led A2 Bit 10 = Led DOWN arrow
Bit 5 = Led A3 Bit 11 = Led point time 1
RO 0
1014
Key status (0=released, 1=pressed)
Bit 0 = Key UP arrow Bit 2 = Key FNC
Bit 1 = Key DOWN arrow Bit 3 = Key SET
RO 0
1015 Cold junction temperature (degrees with tenth) RO -
1016 Current CT istantaneous (Ampere with tenth) RO 0
1017 Current CT average (Ampere with tenth) RO 0
1018 Current CT ON (Ampere with tenth) RO 0
1019 Current CT OFF (Ampere with tenth) RO 0
1100 AI1 value with decimal point selection RO -
1101 AI2 value with decimal point selection RO -
1102 Average between AI1 and AI2 [(AI1 + AI2) /2] with decimal point selection RO 0
1103 Difference between AI1 and AI2 (AI1 - AI2) with decimal point selection RO 0
1104
Module of the difference between AI1 and AI2 (|AI1 - AI2|) with decimal
point selection
RO 0
1105 Sum of AI1 and AI2 (AI1 + AI2) with decimal point selection RO 0
1106
Real setpoint (gradient) of the regulation loop 1 with decimal point
selection
RO 0
1107
Real setpoint (gradient) of the regulation loop 2 with decimal point
selection
RO 0
1200 Setpoint 1 of regulation loop 1 (degrees with tenth) R/W EEPROM
1201 Setpoint 2 of regulation loop 1 (degrees with tenth) R/W EEPROM
1202 Setpoint 3 of regulation loop 1 (degrees with tenth) R/W EEPROM
1203 Setpoint 4 of regulation loop 1 (degrees with tenth) R/W EEPROM
1204 Setpoint 1 of regulation loop 2 (degrees with tenth) R/W EEPROM
1205 Setpoint 2 of regulation loop 2 (degrees with tenth) R/W EEPROM
1206 Setpoint 3 of regulation loop 2 (degrees with tenth) R/W EEPROM
1207 Setpoint 4 of regulation loop 2 (degrees with tenth) R/W EEPROM
1208 Alarm 1 setpoint (degrees with tenth) R/W EEPROM
1209 Alarm 2 setpoint (degrees with tenth) R/W EEPROM
1210 Alarm 3 setpoint (degrees with tenth) R/W EEPROM
1211 Alarm 4 setpoint (degrees with tenth) R/W EEPROM
1212 Alarm 5 setpoint (degrees with tenth) R/W EEPROM
1213 Alarm 6 setpoint (degrees with tenth) R/W EEPROM
