22 - ATR244 - User manual
Modbus
address
Description
Read
Write
Reset
value
1214
Start/Stop
0=controller in STOP
1=controller in START
R/W 0
1215
Hold conversion ON/OFF
0=Hold conversion OFF
1=Hold conversion ON
R/W 0
1216
Tune management for regulation loop 1
With automatic Tune (par. 73
t u n .1 = Auto):
0=autotunig function OFF
1=autotuning ON
RO 0
With manual Tune (par. 73
t u n .1 = manu. or On cE):
0=autotunig function OFF
1=autotuning ON
R/W 0
With synchronized Tune (par. 73
t u n .1 = SY n cH.):
0=autotunig function OFF
1=command output OFF (forces the cooling)
2=command output ON (forces the heating)
3=autotuning ON
4=autotuning ended
R/W 0
1217
Tune management for regulation loop 2
With automatic Tune (par. 98
tun.2 = Auto):
0=autotunig function OFF
1=autotuning ON
RO 0
With manual Tune (par. 98
tun.2 = manu. or On cE):
0=autotunig function OFF
1=autotuning ON
R/W 0
With synchronized Tune (par. 98
tun.2 = SYn cH.):
0=autotunig function OFF
1=command output OFF (forces the cooling)
2=command output ON (forces the heating)
3=autotuning ON
4=autotuning ended
R/W 0
1218
Automatic/manual selection for regulation loop 1
0=automatic; 1=manual
R/W 0
1219
Automatic/manual selection for regulation loop 2
0=automatic; 1=manual
R/W 0
1220
Command output percentage for regulation loop 1 (0-10000)
Heating output percentage with regulation 1 in double loop (0-10000)
R/W 0
1221
Command output percentage for regulation loop 1 (0-1000)
Heating output percentage with regulation 1 in double loop (0-1000)
R/W 0
1222
Command output percentage for regulation loop 1 (0-100)
Heating output percentage with regulation 1 in double loop (0-100)
R/W 0
1223 Cooling output percentage with regulation 1 in double loop (0-10000) RO 0
1224 Cooling output percentage with regulation 1 in double loop (0-1000) RO 0
1225 Cooling output percentage with regulation 1 in double loop (0-100) RO 0
1226
Command output percentage for regulation loop 2 (0-10000)
Heating output percentage with regulation 2 in double loop (0-10000)
R/W 0
1227
Command output percentage for regulation loop 2 (0-1000)
Heating output percentage with regulation 2 in double loop (0-1000)
R/W 0
1228
Command output percentage for regulation loop 2 (0-100)
Heating output percentage with regulation 2 in double loop (0-100)
R/W 0
1229 Cooling output percentage with regulation 2 in double loop (0-10000) RO 0
