User manual - ATR244 - 23
Modbus
address
Description
Read
Write
Reset
value
1230 Cooling output percentage with regulation 2 in double loop (0-1000) RO 0
1231 Cooling output percentage with regulation 2 in double loop (0-100) RO 0
1232
Command output manual reset for regulation loop 1: write 0 to reset the
command output.
In reading 0=reset not allowed, 1=reset allowed
R/W 0
1233
Alarms manual reset: write 0 to reset all alarms.
In reading 0=reset not allowed, 1=reset allowed
Bit0 = Alarm 1 Bit3 = Alarm 4
Bit1 = Alarm 2 Bit4 = Alarm 5
Bit2 = Alarm 3 Bit5 = Alarm 6
R/W 0
1234
Command output manual reset for regulation loop 2: write 0 to reset the
command output.
In reading 0=reset not allowed, 1=reset allowed
R/W 0
1235 Alarm 1 remote stauts (0=absent, 1=present) R/W 0
1236 Alarm 2 remote stauts (0=absent, 1=present) R/W 0
1237 Alarm 3 remote stauts (0=absent, 1=present) R/W 0
1238 Alarm 4 remote stauts (0=absent, 1=present) R/W 0
1239 Alarm 5 remote stauts (0=absent, 1=present) R/W 0
1240 Alarm 6 remote stauts (0=absent, 1=present) R/W 0
1241 Value AO1 by serial (Par. 298
r t M .1 = md.bus) R/W 0
1242 Value AO2 by serial (Par. 308
rtM.2 = md.bus) R/W 0
1243 Tara di zero AI1 (1=tare; 2=reset tare) R/W 0
1244 Tare of zero AI2 (1=tare; 2=reset tare) R/W 0
1245
Tare of zero average between AI1 and AI2 [(AI1 + AI2) /2]
(1=tare; 2=reset tare)
R/W 0
1246
Tare of zero difference between AI1 and AI2 (AI1 - AI2)
(1=tare; 2=reset tare)
R/W 0
1247
Tare of zero module of the difference between AI1 and AI2 (|AI1 - AI2|)
(1=tare; 2=reset tare)
R/W 0
1248
Tare of zero sum of AI1 and AI2 (AI1 + AI2)
(1=tare; 2=reset tare)
R/W 0
1249 Value of remote setpoint by command 1 serial R/W 0
1250 Value of remote setpoint by command 2 serial R/W 0
1300 Setpoint 1 of regulation loop 1, with decimal point selection R/W EEPROM
1301 Setpoint 2 of regulation loop 1, with decimal point selection R/W EEPROM
1302 Setpoint 3 of regulation loop 1, with decimal point selection R/W EEPROM
1303 Setpoint 4 of regulation loop 1, with decimal point selection R/W EEPROM
1304 Setpoint 1 of regulation loop 2, with decimal point selection R/W EEPROM
1305 Setpoint 2 of regulation loop 2, with decimal point selection R/W EEPROM
1306 Setpoint 3 of regulation loop 2, with decimal point selection R/W EEPROM
1307 Setpoint 4 of regulation loop 2, with decimal point selection R/W EEPROM
1308 Alarm 1 setpoint, with decimal point selection R/W EEPROM
1309 Alarm 2 setpoint, with decimal point selection R/W EEPROM
1310 Alarm 3 setpoint, with decimal point selection R/W EEPROM
1311 Alarm 4 setpoint, with decimal point selection R/W EEPROM
1312 Alarm 5 setpoint, with decimal point selection R/W EEPROM
1313 Alarm 6 setpoint, with decimal point selection R/W EEPROM
2001 Parameter 1 R/W EEPROM
2002 Parameter 2 R/W EEPROM
... Parameter ... R/W EEPROM
2366 Parameter 366 R/W EEPROM
