User’s Manual of GS-5220-16S8C & GS-5220-16S8CR
Figure 4-6-7: Port Isolation Configuration Page Screenshot
The Page includes the following fields:
Object Description
 Port Members
A check box is provided for each port of a private VLAN. When checked, port
isolation is enabled on that port. When unchecked, port isolation is disabled on
that port.
By default, port isolation is disabled on all ports.
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
Auto-refresh
: Check this box to refresh the Page automatically. Automatic refresh occurs every 3 seconds.
: Click to refresh the Page immediately.
120
