User’s Manual of GS-5220-16S8C & GS-5220-16S8CR
ï‚· Utilization The best estimate of the mean physical layer network utilization on this interface
during this sampling interval, in hundredths of a percent.
Buttons
: Click to refresh the Page immediately.
Auto-refresh
: Check this box to refresh the Page automatically. Automatic refresh occurs every 3 seconds.
: Updates the table, starting from the first entry in the History table, i.e., the entry with the lowest History
Index and Sample Index
: Updates the table, starting with the entry after the last entry currently displayed.
4.17.7 RMON Statistics Configuration
Configure RMON Statistics table on this Page. The entry index key is ID; screen in Figure 4-17-7 appears.
Figure 4-17-7: RMON Statistics Configuration Page Screenshot
The Page includes the following fields:
Object Description
ï‚· Delete
Check to delete the entry. It will be deleted during the next save.
ï‚· ID
Indicates the index of the entry. The range is from 1 to 65535.
ï‚· Data Source
Indicates the port ID which wants to be monitored. If in stacking switch, the value
must add 1000*(switch ID-1), for example, if the port is switch 3 port 5, the value
is 2005
Buttons
: Click to add a new community entry.
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
327
