User’s Manual of GS-5220-16S8C & GS-5220-16S8CR
Th
is value is restricted to 1-100. This parameter is only shown if "Scheduler
Mode" is set to "Weighted".
The default value is "17".
Weight
Show
s the weight in percent for this queue. This parameter is only shown if
"Scheduler Mode" is set to "Weighted".
 Queue Scheduler
Percent
Controls
whether the port shaper is enabled for this switch port.
 Port Shaper Enable
Controls the ra
te for the port shaper.
This value is restricted to 100-1000000 when the "Unit" is "kbps", and it is
restricted to 1-13200 when the "Unit" is "Mbps".
The default value is 500.
 Port Shaper Rate
Controls the un
it of measure for the port shaper rate as "kbps" or "Mbps".
The default value is "kbps".
 Port Shaper Unit
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
: Click to undo any changes made locally and return to the previous Page.
4.9.6 Port Tag Remarking
This Page provides an overview of QoS Egress Port Tag Remarking for all switch ports. The Port Tag Remarking screen in
Figure 4-9-6 appears.
Figure 4-9-6: QoS Egress Port Tag Remarking Page Screenshot
188
