User’s Manual of GS-5220-16S8C & GS-5220-16S8CR
 Auto-negotiation
Capabilities
Auto-negotiation Capabilities shows the link partners MAC/PHY capabilities.
Buttons
: Click to refresh the Page immediately.
Auto-refresh
: Check this box to refresh the Page automatically. Automatic refresh occurs every 3 seconds.
4.14.5 Neighbor
This Page provides a status overview for all LLDP neighbors. The displayed table contains a row for each port on which an
LLDP neighbor is detected. The LLDP Neighbor Information screen in Figure 4-14-4 appears.
Figure 4-14-4: LLDP Neighbor Information Page Screenshot
The Page includes the following fields:
Object Description
 Local Port
The port on which the LLDP frame was received.
 Chassis ID
The Chassis ID is the identification of the neighbor's LLDP frames.
 Port ID
The Port ID is the identification of the neighbor port.
 Port Description
Port Description is the port description advertised by the neighbor unit.
 System Name
System Name is the name advertised by the neighbor unit.
 System Capabilities
System Capabilities describes the neighbor unit's capabilities. The possible
capabilities are:
1. Other
2. Repeater
3. Bridge
4. WLAN Access Point
5. Router
6. Telephone
307
