User’s Manual of GS-5220-16S8C & GS-5220-16S8CR
 MD5: An optional flag to indicate that this user using MD5 authentication
protocol.
 SHA: An optional flag to indicate that this user using SHA authentication
protocol.
The value of security level cannot be modified if entry already exist. That means
must first ensure that the value is set correctly.
 Authentication
Password
A string identifying the authentication pass phrase. For MD5 authentication
protocol, the allowed string length is 8 to 32. For SHA authentication protocol, the
allowed string length is 8 to 40. The allowed content is the ASCII characters from
33 to 126.
 Privacy Protocol
Indicates the privacy protocol that this entry should belong to. Possible privacy
protocol are:
 None: None privacy protocol.
 DES: An optional flag to indicate that this user using DES authentication
protocol.
 AES: An optional flag to indicate that this user uses AES authentication
protocol.
 Privacy Password
A string identifying the privacy pass phrase. The allowed string length is 8 to 32,
and the allowed content is the ASCII characters from 33 to 126.
Buttons
: Click to add a new user entry.
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
4.3.5.3 SNMPv3 Groups
Configure SNMPv3 groups table on this Page. The entry index keys are Security Model and Security Name. The SNMPv3
Groups screen in Figure 4-3-6 appears.
Figure 4-3-6: SNMPv3 Groups Configuration Page Screenshot
80
