User’s Manual of GS-5220-16S8C & GS-5220-16S8CR
The Page includes the following fields:
Object Description
 VLAN ID
The VLAN ID of the entry.
 Querier Version
Working Querier Version currently.
 Host Version
Working Host Version currently.
 Querier Status
Shows the Querier status is "ACTIVE" or "IDLE".
"DISABLE" denotes the specific interface is administratively disabled.
 Querier Transmitted
The number of Transmitted Querier.
 Querier Received
The number of Received Querier.
 V1 Reports Received
The number of Received V1 Reports.
 V2 Reports Received
The number of Received V2 Reports.
 V1 Leave Received
The number of Received V1 Leaves.
 Router Port
Display which ports act as router ports. A router port is a port on the Ethernet
switch that leads towards the Layer 3 multicast device or MLD querier.
 Static denotes the specific port is configured to be a router port.
 Dynamic denotes the specific port is learnt to be a router port.
 Both denote the specific port is configured or learnt to be a router port.
 Port
Switch port number.
 Status
Indicates whether specific port is a router port or not.
Buttons
: Click to refresh the Page immediately.
: Clears all Statistics counters.
Auto-refresh : Automatic refresh occurs every 3 seconds.
4.8.14 MLD Group Information
Entries in the MLD Group Table are shown on this Page. The MLD Group Table is sorted first by VLAN ID, and then by group.
Each Page shows up to 99 entries from the MLD Group table, default being 20, selected through the "entries per Page" input
field. When first visited, the web Page will show the first 20 entries from the beginning of the MLD Group Table.
The "Start from VLAN", and "group" input fields allow the user to select the starting point in the MLD Group Table. The MLD
Groups Informatino screen in Figure 4-8-17 appears.
171
