User’s Manual of GS-5220-16S8C & GS-5220-16S8CR
4.10.5 ACL Rate Limiter Configuration
Configure the rate limiter for the ACL of the switch.
The ACL Rate Limiter Configuration screen in Figure 4-10-5 appears.
Figure 4-10-5: ACL Rate Limiter Configuration Page Screenshot
The Page includes the following fields:
Object Description
The rate limiter ID for the setti
ngs contained in the same row.
 Rate Limiter ID
The allowed values are: 0-3276700 in pps or 0, 100, 200, 300, ..., 1000000 in
kbps.
 Rate (pp
s
)
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
224
