User’s Manual of GS-5220-16S8C & GS-5220-16S8CR
4.2.16 Fault Alarm
This Page facilitates an update of the firmware controlling the switch. The Web Firmware Upgrade screen in Figure 4-2-19
appears.
Figure 4-2-19: Fault Alarm Control Configuration Page Screenshot
The Page includes the following fields:
Object Description
ï‚· Enable
Controls whether Fault Alarm is enabled on this switch.
ï‚· Record
Controls whether Record is sending System log or SNMP Trap or both.
ï‚· Action
Controls whether Port Fail or Power Fail or both for fault detecting.
ï‚· Power Alarm
Controls whether AC or DC or both for fault detecting.
ï‚· Port Alarm
Controls which Ports or all for fault detecting.
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
64
