User’s Manual of GS-5220-16S8C & GS-5220-16S8CR
 Month - Select the starting month.
 Hours - Select the starting hour.
 Minutes - Select the starting minute.
 End Time Settings  Week - Select the ending week number.
 Day - Select the ending day.
 Month - Select the ending month.
 Hours - Select the ending hour.
 Minutes - Select the ending minute
 Offset Settings
Enter the number of minutes to add during Daylight Saving Time. ( Range: 1 to
1440 )
Buttons
: Click to apply changes.
: Click to undo any changes made locally and revert to previously saved values.
4.2.8 UPnP
Configure UPnP on this Page. UPnP is an acronym for Universal Plug and Play. The goals of UPnP are to allow devices to
connect seamlessly and to simplify the implementation of networks in the home (data sharing, communications, and
entertainment) and in corporate environments for simplified installation of computer components. The UPnP Configuration
screen in Figure 4-2-10 appears.
Figure 4-2-10: UPnP
Configuration Page Screenshot
The Page includes the following fields:
Object Description
 Mode
Indicates the UPnP operation mode. Possible modes are:
 Enabled: Enable UPnP mode operation.
 Disabled: Disable UPnP mode operation.
54
