User’s Manual of GS-5220-16S8C & GS-5220-16S8CR
values are in the range 1 to 200000000.
ï‚· Priority
Controls the port priority. This can be used to control priority of ports having
identical port cost.
Buttons
: Click to set MSTx configuration
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
4.7.8 Port Status
This Page displays the STP CIST port status for port physical ports in the currently selected switch.
The STP Port Status screen in Figure 4-7-11 appears.
Figure 4-7-11: STP Port Status Page Screenshot
The Page includes the following fields:
148
