Planet GS-5220-16S8CR User Manual

User’s Manual of GS-5220-16S8C & GS-5220-16S8CR
273
Buttons
: Click to add a new access management entry.
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
4.12.3 Access Management Statistics
This Page provides statistics for access management. The Access Management Statistics screen in Figure 4-12-3 appears.
Figure 4-12-3: Access Management Statistics Overview Page Screenshot
The Page includes the following fields:
Object Description
 Interface
The interface that allowed remote host can access the switch.
 Receive Packets
The received packets number from the interface under access management
mode is enabled.
 Allow Packets
The allowed packets number from the interface under access management
mode is enabled.
 Discard Packets
The discarded packets number from the interface under access management
mode is enabled.
Buttons
Auto-refresh : Check this box to refresh the Page automatically. Automatic refresh occurs every 3 seconds.
: Click to refresh the Page immediately.
: Clears all statistics.
