User’s Manual of GS-5220-16S8C & GS-5220-16S8CR
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
4.9.3 Port Classification
This Page allows you to configure the basic QoS Ingress Classification settings for all switch ports. The Port Classification
screen in Figure 4-9-2 appears.
Figure 4-9-2 : QoS Ingress Port Classification Page Screenshot
The Page includes the following fields:
Object Description
 Port
The port number for which the configuration below applies.
 CoS
Controls the default class of service.
All frames are classified to a CoS. There is a one to one mapping between CoS,
queue and priority. A CoS of 0 (zero) has the lowest priority.
If the port is VLAN aware and the frame is tagged, then the frame is classified to
183
