User’s Manual of GS-5220-16S8C & GS-5220-16S8CR
184
a CoS that is based on the PCP value in the tag as shown below. Otherwise the
frame is classified to the default CoS.
PCP value:01234567
CoS value:10234567
The classified CoS can be overruled by a QCL entry.
Note: If the default CoS has been dynamically changed, then the actual default
CoS is shown in parentheses after the configured default CoS.
Controls the de
fault drop precedence level.
All frames are classified to a drop precedence level.
If the port is VLAN aware and the frame is tagged, then the frame is classified to
a DPL that is equal to the DEI value in the tag. Otherwise the frame is classified
to the default DPL. The classified DPL can be overruled by a QCL entry
ï‚· DPL
Click to Enab
le DSCP Based QoS Ingress Port Classification.
ï‚· DSCP Based
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
