User’s Manual of GS-5220-16S8C & GS-5220-16S8CR
1.5 Product Specifications
Product GS-5220-16S8C GS-5220-16S8CR
Hardware Specifications
Copper Ports
8 10/ 100/1000Base-T RJ-45 Auto-MDI/MDI-X ports, shared with Port-1~Port-8
SFP/mini-GBIC Slots
24 100/1000Base-X Dual Speed SFP interfaces
Console
1 x RS-232-to-RJ45 serial port (115200, 8, N, 1)
Switch Architecture
Store-and-Forward
Switch Fabric
48Gbps / non-blocking
Throughput
35.7Mpps@64Bytes
Address Table
16K entries, automatic source address learning and ageing
Share Data Buffer
16M bits
Flow Control
IEEE 802.3x pause frame for full-duplex
Back pressure for half-duplex
Jumbo Frame
10K bytes
Reset Button
< 5 sec: System reboot
> 5 sec: Factory default
Dimensions (W x D x H)
440 x 200 x 44.5 mm, 1U height
Weight
2745g
LED
System:
PWR (Greed)
DC (Green) (GS-5220-16S8CR Only)
Fault (Red)
FAN (Red)
10/100/1000T RJ45 Interfaces (Port 1 to Port 8):
1000Mbps LNK/ACT (Green)
10/100Mbps LNK/ACT (Orange)
100/1000Mbps SFP Interfaces (Port 1 to Port 24):
1000Mbps LNK/ACT (Green)
100Mbps LNK/ACT (Orange)
Power Requirements – AC
AC 100~240V, 50/60Hz AC 100~240V, 50/60Hz
Power Requirements – DC
---
48V DC @ 0.6A
Range: 36 ~ 60V
Power Consumption
45 watts / 153 BTU ( max.)
ESD Protection
6KV DC
Layer 2 Functions
Port Configuration
Port disable / enable
Auto-negotiation 10/100/1000Mbps full and half duplex mode selection
Flow control disable / enable
Port Status
Display each port’s speed duplex mode, link status, flow control status,
auto-negotiation status, trunk status
Port Mirroring
TX / RX / Both
Many-to-1 monitor
VLAN
802.1Q Tagged based VLAN
Q-in-Q tunneling
Private VLAN Edge (PVE)
18
