User’s Manual of GS-5220-16S8C & GS-5220-16S8CR
Buttons
: Click to translate all dynamic entries to static entries.
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
4.12.11 IP Source Guard Static Table
This Page provides Static IP Source Guard Table. The Static IP Source Guard Table screen in Figure 4-12-11 appears.
Figure 4-12-11: Static IP Source Guard Table Screen Page Screenshot
The Page incl
udes the following fields:
Object Description
 Delete
Check to delete the entry. It will be deleted during the next save.
 Port
The logical port for the settings.
 VLAN ID
The VLAN ID for the settings.
 IP Address
Allowed Source IP address.
 MAC Address
Allowed Source MAC address.
Buttons
: Click to add a new entry to the Static IP Source Guard table.
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
283
