User’s Manual of GS-5220-16S8C & GS-5220-16S8CR
7. DOCSIS cable device
8. Station only
9. Reserved
When a capability is enabled, the capability is followed by (+). If the capability is
disabled, the capability is followed by (-).
 Management Address
Management Address is the neighbor unit's address that is used for higher layer
entities to assist the discovery by the network management. This could for
instance hold the neighbor's IP address.
Buttons
: Click to refresh the Page immediately.
Auto-refresh
: Check this box to refresh the Page automatically. Automatic refresh occurs every 3 seconds.
4.14.6 Port Statistics
This Page provides an overview of all LLDP traffic. Two types of counters are shown. Global counters are counters that refer to
the whole stack, switch, while local counters refers to counters for the currently selected switch. The LLDP Statistics screen in
Figure 4-14-5 appears.
Figure 4-14-5: LLDP Statistics Page Screenshot
308
