Figure 4-8-18: MLD SSM Information Page Screenshot
The Page includes the following fields:
Object Description
 VLAN ID
VLAN ID of the group.
 Group
Group address of the group displayed.
 Port
Switch port number.
 Mode
Indicates the filtering mode maintained per (VLAN ID, port number, Group
Address) basis. It can be either Include or Exclude.
 Source Address
IP Address of the source. Currently, system limits the total number of IP source
addresses for filtering to be 128.
 Type
Indicates the Type. It can be either Allow or Deny.
 Hardware Filter/Switch
Indicates whether data plane destined to the specific group address from the
source IPv6 address could be handled by chip or not.
Buttons
Auto-refresh : Automatic refresh occurs every 3 seconds.
: Refreshes the displayed table starting from the input fields.
: Updates the table starting from the first entry in the MLD SFM Information Table.
: Updates the table, starting with the entry after the last entry currently displayed.
173
