Indicates the rate limiter n
umber of the ACE. The allowed range is 1 to 16. When
Disabled is displayed, the rate limiter operation is disabled.
 Rate Limiter
Indicates the p
ort redirect operation of the ACE. Frames matching the ACE are
redirected to the port number.
 Port Redirect
The allowed values are Disabled or a specific port number. When Disabled is
displayed, the port redirect operation is disabled.
 Counter
The counter indicates the number of times the ACE was hit by a frame.
 Modification Buttons
You can modify each ACE (Access Control Entry) in the table using the following
buttons:
: Inserts a new ACE before the current row.
: Edits the ACE row.
: Moves the ACE up the list.
: Moves the ACE down the list.
: Deletes the ACE.
: The lowest plus sign adds a new entry at the bottom of the ACE listings.
Buttons
Auto-refresh : Check this box to refresh the Page automatically. Automatic refresh occurs every 3 seconds.
: Click to refresh the Page; any changes made locally will be undone.
: Click to clear the counters.
: Click to remove all ACEs.
