User’s Manual of GS-5220-16S8C & GS-5220-16S8CR
mesRx received by the switch.
Rx
Logoff
dot1xAuthEapolLogoffFr
amesRx
The number of valid EAPOL
Logoff frames that have
been received by the switch.
Rx
Invalid Type
dot1xAuthInvalidEapolF
ramesRx
The number of EAPOL
frames that have been
received by the switch in
which the frame type is not
recognized.
Rx
Invalid Length
dot1xAuthEapLengthErr
orFramesRx
The number of EAPOL
frames that have been
received by the switch in
which the Packet Body
Length field is invalid.
Tx
Total
dot1xAuthEapolFrames
Tx
The number of EAPOL
frames of any type that have
been transmitted by the
switch.
Tx
Request ID
dot1xAuthEapolReqIdFr
amesTx
The number of EAPOL
Request Identity frames that
have been transmitted by
the switch.
Tx
Requests
dot1xAuthEapolReqFra
mesTx
The number of valid EAPOL
Request frames (other than
Request Identity frames)
that have been transmitted
by the switch.
These backend (RADIUS) frame counters are available for the following administrative
states:
■ Port-based 802.1X
■ Single 802.1X
■ Multi 802.1X
■ MAC-based Auth.
 Backend Server
Counters
Direction Name IEEE Name Description
244
