User’s Manual of GS-5220-16S8C & GS-5220-16S8CR
Tx
Responses
dot1xAuthBackendResp
onses
802.1X-based:
Counts the number of times
that the switch attempts to
send a supplicant's first
response packet to the
backend server. Indicates the
switch attempted
communication with the
backend server. Possible
retransmissions are not
counted.
MAC-based:
Counts all the backend server
packets sent from the switch
towards the backend server
for a given port (left-most
table) or client (right-most
table). Possible
retransmissions are not
counted.
Information about the last supplicant/client that attempted to authenticate. This
information is available for the following administrative states:
■ Port-based 802.1X
■ Single 802.1X
■ Multi 802.1X
■ MAC-based Auth.
 Last Supplicant/Client
Info
Name
IEEE Name Description
MAC
Address
dot1xAuthLastEapolF
rameSource
The MAC address of the last supplicant/client.
VLAN ID
- The VLAN ID on which the last frame from the
last supplicant/client was received.
Version
dot1xAuthLastEapolF
rameVersion
802.1X-based:
The protocol version number carried in the most
recently received EAPOL frame.
MAC-based:
Not applicable.
246
