User’s Manual of GS-5220-16S8C & GS-5220-16S8CR
Gigabit Ethernet Transceiver (1000Base-BX, Single Fiber Bi-Directional SFP)
Model Speed (Mbps)
Connector
Interface
Fiber Mode Distance Wavelength (TX) Wavelength (RX) Operating Temp.
MGB-LA10 1000 WDM(LC) Single Mode 10km 1310nm 1550nm 0 ~ 60 ℃
MGB-LB10 1000 WDM(LC) Single Mode 10km 1550nm 1310nm 0 ~ 60 ℃
MGB-LA20 1000 WDM(LC) Single Mode 20km 1310nm 1550nm 0 ~ 60 ℃
MGB-LB20 1000 WDM(LC) Single Mode 20km 1550nm 1310nm 0 ~ 60 ℃
MGB-LA40 1000 WDM(LC) Single Mode 40km 1310nm 1550nm 0 ~ 60 ℃
MGB-LB40 1000 WDM(LC) Single Mode 40km 1550nm 1310nm 0 ~ 60 ℃
MGB-LA60 1000 WDM(LC) Single Mode 60km 1310nm 1550nm 0 ~ 60 ℃
MGB-LB60 1000 WDM(LC) Single Mode 60km 1550nm 1310nm 0 ~ 60 ℃
MGB-TLA10 1000 WDM(LC) Single Mode 10km 1310nm 1550nm -40 ~ 75 ℃
MGB-TLB10 1000 WDM(LC) Single Mode 10km 1550nm 1310nm -40 ~ 75 ℃
MGB-TLA20 1000 WDM(LC) Single Mode 20km 1310nm 1550nm -40 ~ 75 ℃
MGB-TLB20 1000 WDM(LC) Single Mode 20km 1550nm 1310nm -40 ~ 75 ℃
MGB-TLA40 1000 WDM(LC) Single Mode 40km 1310nm 1550nm -40 ~ 75 ℃
MGB-TLB40 1000 WDM(LC) Single Mode 40km 1550nm 1310nm -40 ~ 75 ℃
MGB-TLA60 1000 WDM(LC) Single Mode 60km 1310nm 1550nm -40 ~ 75 ℃
MGB-TLB60 1000 WDM(LC) Single Mode 60km 1550nm 1310nm -40 ~ 75 ℃
1. It is recommended to use PLANET SFP on the Managed Switch. If you insert an SFP transceiver
that is not supported, the Managed Switch will not recognize it.
1. Before we connect the GS-5220-16S8C/GS-5220-16S8CR to the other network device, we have to make sure both sides
of the SFP transceivers are with the same media type, for example: 1000Base-SX to 1000Base-SX, 1000Bas-LX to
1000Base-LX.
2. Check whether the fiber-optic cable type matches with the SFP transceiver requirement.
 To connect to 1000Base-SX SFP transceiver, please use the multi-mode fiber cable with one side being the male
duplex LC connector type.
 To connect to 1000Base-LX SFP transceiver, please use the single-mode fiber cable with one side being the male
duplex LC connector type.

 Connect the Fiber Cable
1. Insert the duplex LC connector into the SFP transceiver.
2. Connect the other end of the cable to a device with SFP transceiver installed.
3. Check the LNK/ACT LED of the SFP slot on the front of the Managed Switch. Ensure that the SFP transceiver is operating
correctly.
4. Check the Link mode of the SFP port if the link fails. To function with some fiber-NICs or Media Converters, user has to set
the port Link mode to “1000 Force” or “100 Force”.
