Channels
Channels
Channels allow you to work with other photographers or keep your triggering exclusive. Some Channels operate on
different frequencies to help you avoid radio interference. All PocketWizard radios set to the same Channel work
together.
This section has Channel tables for the USA FCC / IC (Industry Canada) frequency radios that operate between 340
and 354 MHz. If you have CE frequency radios that operate between 433.42 and 434.42 MHz range then visit the CE
Channels page.
There are two kinds of PocketWizard Channels: Standard Channels and ControlTL Channels.
Standard Channels
Standard Channels are used when triggering a Plus series,MultiMAX or other PocketWizard radio that performs
triggering only and not power control or TTL functions.
Standard Channels 1 through 16
Standard Channels 1 through 16 are considered Classic or Legacy Channels and are the most basic PocketWizard
Channels. They are used for simple triggering scenarios, and contain no zones, power control, or TTL functions.
These Channels all exist on the same frequency. Each channel is its own 16-bit digital code on top of that frequency.
The frequency in use for USA FCC/IC radios is 344.04 MHz. The Plus and Plus II radios use only Cannels 1 through
4. The PlusX uses Channels 1 through 10. The Plus III and MultiMAX radios use a total of 32 Channels. 1-16 are
Standard Channels, 17-32 are Quad-Zone Triggering Channels (see below for details).
All other PocketWizard radios use Standard Channels 1 through 16.
Standard Channels 1 through 16
Standard
Channel
Plus and Plus II
only use
channels
1 through 4
All PocketWizard
radios including:
MAX,
MultiMAX,
ControlTL radios,
OEM flashes,
Sekonic meters,
Classics *
1
2
3
4
5
6
7
