1.9
Model Specifications
1
Front Suspension
Suspension Type IQ 42.5
Shocks
Ryde FX HPG w/IFP (STD.)
(Rebuidlable)
Fox Compression Adj. Remote
Resevoir HPG (OPT.)
(Rebuidable)
IFS Spring Rate
lbs/in (N/mm)
100 (17.5)
Spring Installed Length
Inches (cm)
10.55 (26.8)
Front Vertical Travel
Inches (cm)
10 (25.4)
Ski Center Distance
Inches (cm)
42.5 (108)
Camber Inches (cm) 2.25 ± 0.31 (57 ± 7.9)
Toe Out Inches (cm) 0 - 0.12 (0 - 0.31)
Rear Suspension
Suspension Type IQ 121
Front Track Shock (FTS)
Ryde FX HPG w/IFP (STD.)
(Rebuildable)
Fox HPG w/IFP (OPT.)
(Rebuildable)
FTS Spring Rate
lbs/in (N/mm)
130 - 270 (2.3 - 4.8)
FTS Spring Installed
Length Inches (cm)
7.97 (20.2)
Rear Track Shock (RTS)
Fox PS5 w/IFP (STD.)
(Rebuildable)
Fox Compression Adjustable
Remote Resevoir HPG (OPT.)
(Rebuildable)
Torsion Spring Diameter
Tail Angle
.374
80_
Rear Travel Inches (cm) 13.9 (35.3)
