Polaris IQ 2007 User Manual

1.18
Model Specifications
2007 700 HO RMK Dragon
Model Number: S07PL7JS / S07PL7JE
Engine
Engine Type
Liberty Liquid-Cooled /
Case Reed Induction
Model Number S3322-7044-PF7J
Displacement / # Cylinders 700cc / 2
Bore (inches/mm) 3.19 / 81
Stroke (inches/mm) 2.68 / 68
Piston to Cylinder Clearance
(inches/mm)
.0042 - .006 / .109 - .163
Installed Ring Gap
(inches / mm)
Upper: .010 - .018 / .25 - .45
Lower: .014 - .020 / .35 - .50
Operating RPM ±200 8250
Idle RPM 1700
Engagement RPM ±200 3800
VES Spring Color Purple
Fuel Delivery
Type Cleanfire Direct Injection
Throttle Body Marking 1203213
Throttle Body Bore 46mm
TPS Voltage @ Idle 0.95 +/- 0.01 Vdc
Fuel Pressure - PSI (bar) 58 (4.0)
Recommended Fuel Octane
(R+M/2)
91 Non-Oxygenated
Clutch Settings
ALTITUDE
meters
(feet)
DRIVE CLUTCH DRIVEN CLUTCH
Shift
Weight
Clutch Spring
Clutch
Spring
Driven
Helix
Gearing
0-600
(0-2000)
10-66
BLK / GRN
(120 / 340)
(7042083)
BLACK
(155 / 222)
56/42 .36
LWT ER
20:41-76
600-1200
(2000-4000)
10-64
1200-1800
(4000-6000)
10-62
1800-2400
(6000-8000)
10-60
2400-3000
(8000-10000)
10-58
3000-3600
(10000-12000)
10-56
Drive Clutch Bolt Torque: 80 lb.ft. (108Nm)
General
Width (in/cm) 46.5 / 118.1
Length (in/cm) 130 / 330.2
Height (in/cm) 49 / 124.5
Estimated Dry Weight
(lb/kg)
478 / 217
Fuel (Gallons / Liters) 12 / 45.4
Oil (Quarts / Liters) 3.4 / 3.2
Cooling System Capacity
(Quarts / Liters)
6.3 / 6
Brake Fluid DOT 4
Drive Belt
Part Number
Width (inches / cm)
Side Angle
Circumference (inches / cm)
Center Distance (inches / cm)
3211115
1.460 / 3.7
26_
46.77 / 118.8
11.5 / 29.2
Chaincase
Center Distance (inches)
Top Gear (Stock)
Bottom Gear (Stock)
Chain (Stock)
Gear Lube
Capacity (oz / ml)
Reverse System
8.373
20
41
76
Polaris Synthetic
11 / 325.3
Perc
Electrical
Alternator Output
Operating Voltage
Watts @ 13.5 Vdc (Total)
13.5 - 14.5 Vdc
400
Ignition Timing
18_ @1700 RPM
Coolant Temp = 120_F (49_C)
Spark Plug Gap in.(mm) .027 (.70)
Spark Plug Champion RN57YCC
Track
Width - Inches (cm) 15 (38)
Length - Inches (cm) 155 (393.7)
Lug Height - Inches (cm) 2.4 (6.1)
Track tension sag in/cm with
10 lbs/4.54kg placed 16 in/
40cm ahead of rear idler shaft
3/8
″- 1/2″ (1 - 1.3cm)
