Shocks
SPECIFICATIONS
2007 Shock Specifications
Front Suspension Shocks
SHOCK PN
MODEL
EXTENDED
LENGTH
IN
COLLAPSED
LENGTH
IN
STROKE
IN
SHOCK
ROD
IN
IFP DEPTH
IN
OIL VOLUME
PSI
7042258 Ryde FX 18.00 11.8 6.2 .49 6.92 Full 200
7043245 Ryde FX 18.00 11.8 6.2 .49 6.92 Full 200
7043141 Fox 18.00 11.8 6.2 .50 1.42 Full 200
7043268
(LH)
7043269
(RH)
Fox 18.00 11.8 6.2 .49 2.55 Full 200
7043095 Walker Evans 18.00 11.738 6.27 .625 2.25 Full 200
7043090 Ryde FX 17.00 11.20 5.80 .49 6.54 Full 200
7043082 Ryde FX 16.25 12.76 5.25 .49 6.27 Full 280
7043206 Walker Evans 18.00 10.13 6.26 .625 2.25 Full 200
7043233 Walker Evans 17.02 11.27 5.75 1.124 N/A 95cc
215
220 - 225 (Opt.)
Front Track Shocks
SHOCK PN
MODEL
EXTENDED
LENGTH
IN
COLLAPSED
LENGTH
IN
STROKE
IN
SHOCK
ROD
IN
IFP DEPTH
IN
OIL VOLUME
PSI
7041975 Ryde FX 12.10 8.60 3.5 .50 4.61 Full 200
7043142 Fox 12.51 8.92 3.59 .50 .840 Full 200
7043244 Ryde FX 12.12 8.61 3.52 .50 4.68 Full 200
7043267 Fox 12.07 8.63 3.44 .50 1.8 Full 200
7043204 Walker Evans 12.10 8.60 3.50 .625 2.25 Full 200
7043234 Walker Evans 12.49 8.92 3.57 1.124 N/A 70cc
215
210 - 220 (Opt.)
Rear Track Shocks
SHOCK PN
MODEL
EXTENDED
L
ENGTH
IN
COLLAPSED
L
ENGTH
IN
STROKE
IN
SHOCK
R
OD
IN
IFP DEPTH
IN
OIL VOLUME
PSI
7043177 Fox 15.60 10.56 5.04 .50 1.22 Full 200
7043246 Fox 16.60 10.91 5.96 .50 2.23 Full 200
7043266 Fox 15.65 10.56 5.09 .50 1.63 Full 200
7043205 Walker Evans 15.60 10.56 5.04 .625 2.25 Full 200
7043216 Fox 14.12 9.29 4.83 .50 2.40 Full 300
7043235 Walker Evans 16.71 10.96 5.75 .50 7.25 Full 200
