Model Specifications
2008 800 Dragon RMK 155 / 163
Model Number:
Dragon 155 = S08PG8ES / S08PG8EE
Dragon 163 = S08PH8ES
Engine
Engine Type
Liberty Liquid-Cooled /
Case Reed Induction
Model Number
S3489-8044-PU8E (155)
S3741-8044-PU8E (163)
Displacement / # Cylinders 794cc / 2
Bore (inches/mm) 3.34 / 85
Stroke (inches/mm) 2.75 / 70
Piston to Cylinder Clearance
inches / (mm)
.0037 - .0053 (.095 - .135)
Installed Ring Gap
inches / (mm)
.017 - .025 (.45 - .65)
Operating RPM (+0 / -300) 8250
Idle RPM 1700
Engagement RPM ±200 3800
Exhaust Valve Spring Pink
Fuel Delivery
Type Cleanfire Direct Injection
Throttle Body Marking 1203505
Throttle Body Bore 48 mm
TPS Voltage @ Idle .93 +/- 0.01 Vdc
Fuel Pressure - PSI (bar) 58 (4.0)
Recommended Fuel Octane
(R+M/2)
91 Non-Oxygenated
Clutch Settings
ALTITUDE
meters
(feet)
DRIVE CLUTCH DRIVEN CLUTCH
Shift
Weight
Clutch
Spring
Clutch
Spring
Driven
Helix
Gearing
0-600
(0-2000)
10-68
140 / 330
(7043342)
BLK/PUR
(160 / 240)
(7043363)
56/42 - .36 20:41 - 76
600-1200
(2000-4000)
10-66
1200-1800
(4000-6000)
10-64
1800-2400
(6000-8000)
10-62
2400-3000
(8000-10,000)
10-60
3000-3600
(10,000-12,000)
10-58
Drive Clutch Bolt Torque: 80 lb.ft. (108 Nm)
General
Width (in/cm) 46.5 / 118.1
Length (in/cm) 129 / 327.7
Height (in/cm) 49.5 / 125.7
Estimated Dry Weight (lb/kg)
155
163
487 / 220.9
487 / 220.9
Fuel (Gallons / Liters) 11.5 / 43.5
Oil (Quarts / Liters) 3 / 2.8
Cooling System Capacity
(Quarts / Liters)
155 = 6.5 / 6.1
163 = 6.625 / 6.3
Brake Fluid DOT 4
Drive Belt
Part Number
Width (inches / cm)
Side Angle
Circumference (inches / cm)
Center Distance (inches / cm)
3211115
1.460 / 3.7
26_
46.77 / 118.8
11.5 / 29.2
Chaincase
Center Distance (inches)
Top Gear (Stock)
Bottom Gear (Stock)
Chain (Stock)
Gear Lube
Capacity (oz / ml)
Reverse System
8.373
20
41
76
Polaris Synthetic
11 / 325.3
Perc
Electrical
Alternator Output
Operating Voltage
Watts @ 13.5 Vdc (Total)
13.5 - 14.5 Vdc
400
Ignition Timing
18_ @1700 RPM
Coolant Temp = 120_F (49_C)
Spark Plug Gap in.(mm) .027 (.70)
Spark Plug Champion RN57YCC
Track
Width - Inches (cm) 15 (38)
Length - Inches (cm)
155 (393.7)
163 (414)
Lug Height - Inches (cm) 2.4 (6.1)
Track tension sag in/cm with
10 lbs/4.54kg placed 16 in/
40cm ahead of rear idler shaft
3/8
″- 1/2″ (1 - 1.3cm)
