6.9
Final Drive and Brakes
6
Driveshaft Removal/Installation
1. Remove the side panels.
2. Remove the intake plenum.
3. Remove the drain plug and drain the chaincase fluid.
4. Replace the chaincase drain plug and torque it to 8 ft-lb (11
N-m).
5. Remove the chaincase cover.
6. Loosen the tensioner.
7. Remove the lower sprocket bolt and washer.
8. Shut off the fuel valve if so equipped.
9. Remove the exhaust system.
10. Remove the speedo drive pickup.
11. Remove the speedo drive housing.
12. Remove the rear skid.
13. With the sled over on its left side and the rear skid removed,
remove the drive shaft.
14. Assemble in reverse order
= T
Drain Plug: 8 ft-lb (11 N-m)
