Polaris IQ 2007 User Manual

1.2
Model Specifications
SPECIFICATIONS
2007 600 HO IQ
Model Number: S07PP6FS (A) (B)
Engine
Engine Type
Liberty Liquid-Cooled /
Case Reed Induction
Model Number S3273-6044-PF6F
Displacement / # Cylinders 599cc / 2
Bore (inches/mm) 3.04 / 77.25
Stroke (inches/mm) 2.52 / 64
Piston to Cylinder Clearance
(inches/mm)
.004 - .006 / .105 - .159
Installed Ring Gap
(inches / mm)
.014 - .020 / .356 - .508
Operating RPM ±200 8100
Idle RPM 1500
Engagement RPM ±200 3800
Exhaust Valve Spring Pink
Carburetor Settings
Type
Mikuni TM38
Main Jet
420
Pilot Jet
50
Jet Needle/Clip position
9DGN6-57 / 2
Needle Jet
P-8
Throttle Gap (Under Cutaway) (in/mm)
0.08 / 2.1
Cutaway
1.5 Notch
Valve Seat
1.5
Starter Jet
145
Pilot Air Jet
.6
Fuel screw (Turns Out)
1.25
Recommended Fuel Octane (R+M/2)
91
(Non-Oxygenated)
Carburetor Jetting
Altitude
Meters (feet)
Ambient Temperature
< -25°F/<-35°C
-30°F to -10°F/-34°C to -23°C
-15°F to +5°F/-26°C to -15°C
0°F to +20°F/-18°C to -7°C
+15°F to +35°F/-9°C to +2°C
+30°F to +50°F/-1°C to +10°C
+45°F to +65°F/+7°C to +18°C
>+60°F/>+16°C
0-600
(0-2000)
440
#3
430
#3
420
#2
400
#2
390
#2
380
#2
370
#2
360
#1
600-1200
(2000-4000)
410
#3
400
#3
390
#2
370
#2
360
#2
350
#2
340
#1
330
#1
1200-1800
(4000-6000)
370
#3
360
#2
350
#2
340
#2
330
#2
320
#1
310
#1
300
#1
1800-2400
(6000-8000)
340
#3
320
#2
310
#2
300
#2
280
#2
280
#1
270
#1
260
#1
2400-3000
(8000-10000)
310
#2
300
#2
290
#2
280
#1
270
#1
260
#1
250
#1
240
#1
3000-3700
(10000-12000)
290
#2
280
#2
270
#1
250
#1
240
#1
230
#1
220
#1
210
#1
When using non oxygenated fuel with a RON greater than 93,
decrease the main jet number in the above chart by 10 and raise the
E-clip one position. If the chart recommends clip #1, install washer
on top when using RON 93.
Clutch Settings
ALTITUDE
meters
(feet)
DRIVE CLUTCH DRIVEN CLUTCH
Shift
Weight
Clutch
Spring
Clutch
Spring
Driven
Helix
Gearing
0-600
(0-2000)
10-62
BLK / GRN
(120 / 340)
(7042083)
RED/BLK
(140 / 240)
(7043058)
64/42.36
LW ER
23:39-76
600-1200
(2000-4000)
10-60
56/42 - .36
LW ER
22:39-76
1200-1800
(4000-6000)
10-58
22:40-76
1800-2400
(6000-8000)
10-56
2400-3000
(8000-10000)
10-54
20:41-76
3000-3600
(10000-12000)
10-AL
Drive Clutch Bolt Torque: 50 lb.ft. (68Nm)
