Model Specifications
1
General
Width (in/cm) 48 / 121.9
Length (in/cm) 115 / 292.1
Height (in/cm) 48 / 121.9
Estimated Dry Weight
(lb/kg)
475 / 215.7
Fuel (Gallons / Liters) 10.8 / 40.9
Oil (Quarts / Liters) 3.4 / 3.2
Cooling System Capacity
(Quarts / Liters)
6.3 / 6
Brake Fluid DOT 4
Drive Belt
Part Number
Width (inches / cm)
Side Angle
Circumference (inches / cm)
Center Distance (inches / cm)
3211080
1.438 / 3.65
28_
46.625 / 118.4
11.5 / 29.2
Chaincase
Center Distance (inches)
Top Gear (Stock)
Bottom Gear (Stock)
Chain (Stock)
Gear Lube
Capacity (oz / ml)
Reverse System
8.373
23
39
76
Polaris Synthetic
11 / 325.3
Perc
Electrical
Alternator Output
Operating Voltage
Watts @ 13.5 Vdc (Total)
13.5 - 14.5 Vdc
280
Ignition Timing
26_ @3500 RPM
(TPS Un-plugged)
Spark Plug Gap in.(mm) .027 (.70)
Spark Plug Champion RN57YCC
CDI Marking 4011033
Flywheel Marking 4010677
Track
Width - Inches (cm) 15 (38)
Length - Inches (cm) 121 (307)
Lug Height - Inches (cm)
1.0 / (2.5)
1.25 (3.175) - Option
Track tension sag in/cm with
10 lbs/4.54kg placed 16 in/
40cm ahead of rear idler
shaft
7/8
″ - 1-1/8″(2.2 - 2.9cm)
Front Suspension
Suspension Type IQ 42.5
Shocks
Ryde FX HPG w/IFP (STD.)
(Rebuidlable)
Fox Compression Adj. Remote
Resevoir HPG (OPT.)
(Rebuidable)
IFS Spring Rate
lbs/in (N/mm)
100 (17.5)
Spring Installed Length
Inches (cm)
10.55 (26.8)
Front Vertical Travel
Inches (cm)
10 (25.4)
Suspension Setup
Width
Inches (cm)
41.16 (104.54)
Camber Inches (cm) 2.25 ± 0.31 (57 ± 7.9)
Toe Out Inches (cm) 0 - 0.12 (0 - 0.31)
Rear Suspension
Suspension Type IQ 121
Front Track Shock (FTS)
Ryde FX HPG w/IFP (STD.)
(Rebuildable)
Fox HPG w/IFP (OPT.)
(Rebuildable)
FTS Spring Rate
lbs/in (N/mm)
130 - 270 (23 - 47)
FTS Spring Installed
Length Inches (cm)
7.97 (20.2)
Rear Track Shock (RTS)
Fox PS5 w/IFP (STD.)
(Rebuildable)
Fox Compression Adjustable
Remote Resevoir HPG (OPT.)
(Rebuildable)
Torsion Spring Diameter
Tail Angle
.374
80_
Rear Travel Inches (cm) 13.9 (35.3)
