5.46
Engine and Cooling Systems
2008 IQ Shift - CFI 600 / 700 121 and Switchback Cooling System
SURGE TANK
CAP
HOSE - SURGE TANK OUT TO ENGINE IN
HOSE - FRT COOLER
OUT TO SURGE TANK
RH PERIMETER COOLER
LH PERIMETER COOLER
CROSS OVER HOSE
FRONT COOLER
HOSE - TUNNEL COOLERS OUT
TO SURGE TANK
(THERMOSTAT OPEN)
HOSE - ENGINE OUT TO TUNNEL COOLER
HOSE - BYPASS TO
FRT COOLER
