9.13
Shocks
9
2008 Shock Valve Shim Stack Configurations
NOTE: All measurements are in inches.
NOTE: Valve shim stacks listed as they would
appear on the shaft when shock rod is locked in a
table vise (eyelet down, threaded end up).
NOTE: Valve shim stacks listed as they would
appear on the shaft when shock rod is locked in a
table vise (eyelet down, threaded end up).
2008 IFS Shocks
SHOCK 7043245 7043315 7043364
REBOUND
.700 x .008
.800 x .008
.900 x .008
1.000 x .008
1.100 x .008
1.250 x .008
TBA
.625 x .065
.700 x .012
.800 x .012
.900 x .012
1.00 x .012
1.10 x .015
1.20 x .015
1.25 x .010
1.25 x .015
Piston
Orifice
.060 .052
COMPRESSION
1.300 x .008
1.100 x .006
.800 x .008
1.250 x .006
1.100 x .008
1.000 x .006
.900 x .006
.800 x .006
.700 x .015
1.30 x .015
1.20 x .015
1.20 x .010
1.10 x .015
1.10 x .010
1.00 x .015
.900 x .015
.800 x .015
.700 x .015
.875 x .090
2008 Front Track Shocks
SHOCK 7043244 7043365
REBOUND
.700 x .010
.800 x .012
.900 x .010
1.000 x .010
1.100 x .010
1.250 x .010
.625 x .065
.7 x .015
.8 x .015
.9 x .015
1.0 x .015
1.1 x .015
1.2 x .015
1.2 x .015
1.25 x .015
1.25 x .015
1.25 x .015
Piston Orifice .070 .052
COMPRESSION
1.300 x .008
1.100 x .006
.900 x .008
1.250 x .008
1.100 x .008
1.000 x .010
.900 x .010
.800 x .008
1.3 x .010
1.1 x .010
.9 x .012
.7 x .012
1.3 x .012
1.2 x .012
1.1 x .012
1.0 x .012
.9 x .012
.8 x .012
.7 x .012
.625 x .065
