Model Specifications
1
General
Width (in/cm) 46.5 / 115.6
Length (in/cm)
124 / 315 (144)
129 / 327.7 (155)
Height (in/cm) 48 / 121.9
Estimated Dry Weight
(lb/kg)
472 / 214.3 (144)
478 / 216.8 (155)
Fuel (Gallons / Liters) 11.5 / 43.5
Oil (Quarts / Liters) 3 / 2.8
Cooling System Capacity
(Quarts / Liters)
144 = 6.25 / 6
155 = 6.5 / 6.1
Brake Fluid DOT 4
Drive Belt
Part Number
Width (inches / cm)
Side Angle
Circumference (inches / cm)
Center Distance (inches / cm)
3211115
1.460 / 3.7
26_
46.77 / 118.8
11.5 / 29.2
Chaincase
Center Distance (inches)
Top Gear (Stock)
Bottom Gear (Stock)
Chain (Stock)
Gear Lube
Capacity (oz / ml)
Reverse System
8.373
19
41
76
Polaris Synthetic
11 / 325.3
Perc
Electrical
Alternator Output
Operating Voltage
Watts @ 13.5 Vdc (Total)
13.5 - 14.5 Vdc
280
Ignition Timing
26_ @3500 RPM
(TPS Un-plugged)
Spark Plug Gap in.(mm) .027 (.70)
Spark Plug Champion RN57YCC
CDI Marking 4011033
Flywheel Marking 4010677
Track
Width - Inches (cm) 15 (38)
Length - Inches (cm)
144 (365.7)
155 (393.7)
Lug Height - Inches (cm)
2.0 (5.08) (144)
2.4 (6) (155)
Track tension sag in/cm with
10 lbs/4.54kg placed 16 in/
40cm ahead of rear idler
shaft
3/8
″- 1/2″ (1 - 1.3cm)
Front Suspension
Suspension Type IQ RMK
Shocks Ryde FX
IFS Spring Rate
lbs/in (N/mm)
100 (17.5)
Spring Installed Length
Inches (cm)
10.35 (26.2)
Front Vertical Travel
Inches (cm)
9 (22.9)
Ski Center Distance
Inches (cm)
Setup Width
39 - 40 - 41 (99.1 - 101.6 - 104.1)
38.67 (98.2)
Camber Inches (cm) 2.17 ± 0.31 (55 ± 7.9)
Toe Out Inches (cm) 0 - 0.12 (0 - 0.31)
Rear Suspension
Suspension Type IQ RMK 144 / 155
Front Track Shock (FTS) Ryde FX
FTS Spring Rate
lbs/in (N/mm)
190 (33)
Rear Track Shock (RTS)
Ryde AFX
Compression Adjustable
Torsion Springs
.359 Square / 77_ (Stock)
.347 / 77_ / (Soft)
- PN 7041627 - 067
- PN 7041628 - 067
.375 / 77_ / (Firm)
- PN 7041942 - 067
- PN 7041943 - 067
Rear Travel Inches (cm)
14.5 (36.8) (144)
15.5 (39.4) (155)
