Model Specifications
1
General
Width (in/cm) 48 / 121.9
Length (in/cm) 125 / 317.5
Height (in/cm) 48 / 121.9
Estimated Dry Weight
(lb/kg)
483 / 219.3
Fuel (Gallons / Liters) 10.8 / 40.9
Oil (Quarts / Liters) 3.4 / 3.2
Cooling System Capacity
(Quarts / Liters)
6.3 / 6
Brake Fluid DOT 4
Drive Belt
Part Number
Width (inches / cm)
Side Angle
Circumference (inches / cm)
Center Distance (inches / cm)
3211080
1.438 / 3.65
28_
46.625 / 118.4
11.5 / 29.2
Chaincase
Center Distance (inches)
Top Gear (Stock)
Bottom Gear (Stock)
Chain (Stock)
Gear Lube
Capacity (oz / ml)
Reverse System
8.373
22
39
76
Polaris Synthetic
11 / 325.3
Perc
Electrical
Alternator Output
Operating Voltage
Watts @ 13.5 Vdc (Total)
13.5 - 14.5 Vdc
280
Ignition Timing
26_ @3500 RPM
(TPS Un-plugged)
Spark Plug Gap in.(mm) .027 (.70)
Spark Plug Champion RN57YCC
CDI Marking 4011033
Flywheel Marking 4010677
Track
Width - Inches (cm) 15 (38)
Length - Inches (cm) 144 (366)
Lug Height - Inches (cm)
1.25 (3.175) (STD.)
1.50 (3.8) (OPT.)
Track tension sag in/cm with
10 lbs/4.54kg placed 16 in/
40cm ahead of rear idler
shaft
3/8
″- 1/2″ (1 - 1.3cm)
Front Suspension
Suspension Type IQ 42.5
Shocks
Fox HPG w/IFP (STD.)
(Rebuidlable)
Fox Compression Adj. Remote
Resevoir HPG (OPT.)
(Rebuidable)
IFS Spring Rate
lbs/in (N/mm)
100 (17.5)
Spring Installed Length
Inches (cm)
10.55 (26.8)
Front Vertical Travel
Inches (cm)
10 (25.4)
Ski Center Distance
Inches (cm)
42.5 (108)
Camber Inches (cm) 2.25 ± 0.31 (57 ± 7.9)
Toe Out Inches (cm) 0 - 0.12 (0 - 0.31)
Rear Suspension
Suspension Type IQ 144
Front Track Shock (FTS)
Fox HPG w/IFP
(Rebuildable)
FTS Spring Rate
lbs/in (N/mm)
170 (30)
FTS Spring Installed
Length Inches (cm)
7.25 (18.4)
Rear Track Shock (RTS)
Fox Compression Adjustable
Remote Resevoir HPG
(Rebuildable)
Torsion Springs
.359 Square / 77_ (Stock)
.347 / 77_ / (Soft)
- PN 7041627 - 067
- PN 7041628 - 067
.375 / 77_ / (Firm)
- PN 7041942 - 067
- PN 7041943 - 067
Rear Travel Inches (cm) 13.9 (35.3)
