C12
GEARCASE
Scrambler 500 A00BG50AA
Ref. Part No . Qty. Description Ref. Part No. Qty. Description
1341284 1 Asm., Gearcase (Incl. 1-59)(Units built
before April 23, 1999)
1 3233632 1 Gearcase, LH Mach
2 3233018 3 Bearing, Ball
3 3233557 1 Shaft, Reverse 31T
4 3233012 2 Washer, Thrust
5 3233014 1 Bearing, Needle
6 3233532 1 Spr ocket, 24T
7 3233029 1 Ring, Retaining
8 3233533 1 Engagement Dog
9 3233010 1 Washer, Thrust
10 3233633 1 Fork, Shift High/Rev. Mach
11 3233534 1 Bushing, Garlock
12 3233535 1 Gear, 30T
13 3233176 1 Washer, Thrust
14 3233177 1 Ring, Retaining
15 3233019 1 Bearing, Ball
16 3233033 4 Screw
17 3233309 1 Bracket, Interlock
18 3233550 1 Spring, Shifting Interlock
19 3233308 2 Pin, Interlock
20 3233559 1 Shaft, Shift
21 3233040 1 Washer
22 3233547 1 Bellcrank
23 3233055 1 Nut, FLEXLOC
24 3233054 1 Washer
25 3233045 1 Ring, Retaining
26 3233548 1 O-Ring
27 3233616 4 Screw and Washer
28 3233635 1 H/R Switch
29 3233325 1 Plug
30 3233324 1 Washer
31 3233556 1 Cover, Snorkel
32 3233539 11 Screw
33 3233555 1 O-Ring
34 3233248 3 Seal
35 3233554 1 Shim
36 3233553 1 Subassembly, Snorkel Gear
37 3233552 1 Bushing, Garlock
38 3233634 1 Gearcase, RH Mach
39 3233037
8360009-600
1
AR
Tube, Vent
Line, Fuel
40 3233636 1 Decal - Switch
41 3233020 3 Bearing, Ball
42 3233546 1 Chain, Roller 26P
43 3233545 1 Sprocket, 16/26T
44 3233544 1 Shaft, Output
45 3233558 1 Gear, 98T
46 3233537 1 Ring, Retaining
47 3233538 1 Sprocket, 14/22T
48 3233263 1 Bearing, Cover, Center Drive
49 3233306 1 Ring, Retaining
50 3233540 1 Shaft, Pinion 13T
51 3233541 1 Bushing, Garlock
52 3233542 1 Washer, Thrust Button Pinion
53 3233043 1 Deflector, Oil
54 3233036 1 Chain, Silent
55 3233536 1 Shaft, Input
56 3233529 2 Pipe, Knock
57 3233252 11 Screw
58 3233527 1 Bush ing, Pivot
59 3233448 1 Plug
60 3233035 1 Washer
5/99
