C14
GEARCASE
Scrambler 500 A00BG50AA
Ref. Part No . Qty. Description Ref. Part No. Qty. Description
1341328 1 Asm., Gearcase (Incl. 1-57)
(Units built after April 23, 1999)
1 3233632 1 Gearcase, LH Mach
2 3233018 3 Bearing, Ball
3 3233728 1 Shaft, Reverse 31T
4 3233718 2 Bearing, Needle
5 3233719 1 Spr ocket, 24T
6 3233720 2 Ring, Retaining, E-Ring
7 3233721 1 Dog, Engagement
8 3233633 1 Fork, Shift High/Rev., Mach
9 3233722 1 Gear, 30T
10 3233176 1 Washer, Thrust
11 3233177 1 Ring, Retaining
12 3233019 1 Bearing, Ball
13 3233033 4 Screw
14 3233309 1 Bracket, Interlock
15 3233550 1 Spring, Shifting Interlock
16 3233308 2 Pin, Interlock
17 3233559 1 Shaft, Shift
18 3233040 1 Washer
19 3233547 1 Bellcrank
20 3233055 1 Nut, FLEXLOC
21 3233054 1 Washer
22 3233045 1 Ring, Retaining
23 3233548 1 O-Ring
24 3233691 4 Screw and Washer
25 3233635 1 Switch, H /R
26 3233711 1 Plug
27 3233324 1 Washer
28 3233556 1 Cover, Snorkel
29 3233539 11 Screw
30 3233248 3 Seal, Triple Lip
31 3233555 1 O-Ring
32 3233020 4 Bearing, Ball
33 3233554 AR Shim
34 3233723 1 Subassembly, Snorkel Gear
35 3233552 1 Bushing, Garlock
36 3233037
8360009-600
1
AR
Tube, Vent
Line, Fuel
37 3233636 1 Decal - Switch
38 3233798 1 Gearcase, RH Mach
39 3233546 1 Chain, Roller 26P
40 3233545 1 Sprocket, 16/26T
41 3233544 1 Shaft, Output
42 3233558 1 Gear, 98T
43 3233537 1 Ring, Retaining
44 3233538 1 Sprocket, 14/22T
45 3233263 1 Bearing, Cover, Center Drive
46 3233306 1 Ring, Retaining
47 3233540 1 Shaft, Pinion 13T
48 3233541 1 Bushing, Garlock
49 3233542 1 Washer, Thrust Button Pinion
50 3233043 1 Deflector, Oil
51 3233036 1 Chain, Silent
52 3233536 1 Shaft, Input
53 3233529 2 Pipe, Knock
54 3233252 11 Screw
55 3233527 1 Bush ing, Pivot
56 3233448 1 Plug
57 3233035 1 Washer
12/00
