Polaris SCRAMBLER 500 2000 User Manual

D10
CARBURETOR
Scrambler 500 A00BG50AA
Ref. Part No . Qty. Description Ref. Part No. Qty. Description
1 3130821 2 Screw
2 3130914 1 Cover, Diaphragm
3 3130911 1 Spring
4 3130913 1 Ring
5 3130908 1 E-Ring
6 3130915 1 Ring
7 3130918 1 Needle, Jet
8 3130910 1 Diaphragm
9 3130912 1 Valve, Piston
10 3130543 1 Guide, Cable
11 3130931 1 Asm., Throttle Shaft
12 3130932 1 Ring
13 3130927 1 Spring
14 3130933 4 Screw
15 3130926 2 Washer
16 3130925 1 Case
17 3130619 1 Jet, Air
18 3130903 1 Asm., Carburetor (Incl. 1-52)
19 3130920 1 Jet, Needle
20 3131290 1 Block, Jet
21 3130916 1 O-Ring
22 3131208 1 Cap
23 3130593 1 Asm., Plunger
24 3130538 1 Spring
25 3130199 1 Cap, Plunger
26 3130519 1 Cap
27 3130518 1 E-Ring
28 3130517 1 Packing
29 3130515 2 Seal
30 3130906 2 Screw
31 3130907 1 Valve, Throttle (120)
32 3130934 1 Adjuster
33 3130525 1 Spring
34 3130523 1 Washer
35 3130522 1 O-Ring
36 3130624 1 Jet, Pilot (#40)
37 3130922 1 Valve, Needle (1.5)
38 3130928 1 O-Ring
39 3131294 1 O-Ring
40 3130930 1 Cover
41 3130924 3 Screw
42 3130010 1 Spring
43 3130938 1 Asm., Adjuster, Cable
44 3130937 1 Clip
45 3131291 1 Screw, Guide
46 3130239 1 O-Ring
47 3130571 1 Jet, Main (#155)
48 3130919 1 Ring
49 3130935 1 Screw
50 3130923 1 Asm., Float Body
51 3130917 1 Seal
52 3131293 1 Asm., Float
7/00
