Polaroid Spectra/Image One Board - Removing Photodiode Retainer

22
10.Use tweezes to remove the photodiode ratainer from the shutter base block
(Figure 2-13).
11.Lift out the One Board Strobe/Exposure Module Assembly.
Note: To install a One Board Strobe/Exposure Module Assembly, reverse this
procedure.
Figure 2-13. Removing photodiode retainer
Photodiode Retainer
Shutter Baseblock
