60
Figure 4-1. One board strobe/exposure module connections on ranging board
Figure 4-2. Elastomeric “Zebra” connector
One Board
Strobe/Exposure
Module
Ranging
Board
J1
J2
J3
Gold Contact
Fingers
Elastomer
