Star Tester Model 12650-3 Description
This Star Tester is an upgrade of the Model 12650-2 (for 600 Series and other
cameras). The 12650-3 permits testing Spectra System Cameras for seven different
exposure-and timing-related operating characteristics, as well as 600-Series and other
cameras.
Except for a new Horn (P/N 13146) for holding Spectra System Cameras and a few
name changes of Selector Switch positions, the 12650-3 Tester is outwardly identical to
the earlier Model 12650-2 Star Tester.
Model 12650-3 Controls and Indicators
Listed below are the Star Tester 12650 - 3 controls and indicators shown in Figure 3-7.
The integrating light sphere and electronics required to compute and display exposure,
timing and functional characteristics of the camera under test are all housed within the
Tester cabinet.
Figure 3-7
KEY CONTROL/INDICATOR FUNCTION
1 Disc Position Lamps* Not used
2 Reset Button Clears electronics between tests
3 Disc/Ride Time Switch* Selects Test mode (7000 ZLS,
Flash Exposure, Ambient & Blade
Speed for Spectra camera.)
5 Horn Volts Selector Switch Selects 5V (low), 6V (nom) or
6.8V (high). Simulates film pack
battery voltage.
6 20V/2000V Selector With Volt Probe Jack and DC
Voltmeter, allows use of Tester as
voltmeter.
7 Volt Probe Jack For checking DC voltages in
camera under test, with standard
probe.
8 Timing Meter Digital readout of strobe recycle
time or blade speed.
9 DC Voltmeter Digital readout of circuit voltages;
also use with probe in Volt ProbeJack.
* Not used for testing Spectra cameras
