34
Figure 3-7
KEY CONTROL/INDICATOR FUNCTION
10 Stops Error Meter Digital readout for Ambient,
Hybrid, Strobe Expos. Tests.
11 DC Current Meter Digital readout of energy req’d
to charge Strobe capacitor.
12 ZLS Meter Digital readout of strobe light
output in Zonal Lumen seconds.
13 Power Switch AC line voltage On/Off to Tester,
Lights when Tester is powered.
14 Pack Simulator Jack Connection for film pack
simulation voltage. Lets tester
function as a power supply.
15 Strobe Adaptors (two)* Aligns electronic flash of 600/680
camera under test to Star
Tester.
16 Horn Cable Connector Accepts plug on Horn cable.
17 Disc Detector Connector* Accepts cable from 600 Disc
Detect/Ride Time Fixture.
18 J4 Connector* For future applications.
19 Test Point Connectors For connections to oscilloscope.
Also used for calibrating Tester.
* Not used for testing Spectra cameras
Caution: When the tester is not in constant use, turn the
selector switch to 7000 ZLS. This reduces light
source wear and keeps the tester in a neutral state,
ready for immediate resumption of testing.
