Polyend Play Manual Rev 1
NOTES
The main menu MIDI options allow CC Mapping per Port and Per Channel.
This is how Play aligns it’s CC parameters to an external device’s default
CC target parameters. Note that when connecting Polyend Tracker, a
predened preset to control it’s parameters is also available, selectable in
the Play MIDI CC Settings.
▌ CHANGING THE CC MAPPING
1. Refer to the destination devices MIDI denitions. Ensure this is the
device CC denitions and not NRPN as these are not compatible with
Play. The destination target parameters should be identied.
2. The default MIDI Control parameters are assigned to Knobs for CC#’s
12, 13, 17, 19, 22, 71, 74 and 75. These can be changed.
3. Press (Screen) to open the main conguration menu. Turn the (Screen)
knob to navigate to highlight ‘MIDI’. Press (Screen) to open the MIDI
sub-menu. If the menu is not at the main menu, press [Back] to backup.
4. Turn the (Screen) knob to navigate to highlight ‘CC Mapping’. Press
(Screen) to open the CC Mapping sub-menu.
5. Turn the (Screen) knob to navigate to highlight the MIDI output port and
channel to congure the CC’s. The Jack refers to the MIDI out
connected with the 5-Pin DIN Adaptor and USB refers to the same
connection as power. Press (Screen) to open the Port /Channel
mapping page.
6. The 8 CC Parameter congurations, represented by the 4 physical
knobs are listed. In addition the option to set the mapping to match
Polyend Tracker is also listed.
7. Turn (Screen) to highlight the knob parameter to change and Press
(Screen) to select it for editing.
8. The CC# list is presented. Turn (Screen) to highlight the CC# that
represents the destination parameter to assign. Press (Screen) to select
the highlighted number.
9. Continue by iterating through the steps 7-8 to edit other controls if
required.
