THE ART OF WELDING
P6
20-92 PN-0509076 Rev. 16
Technical characteristics3. 4.
Mains power source
Threephase + earth
400 V/415 V ± 10 %
50 or 60 Hz
Multivoltage option 200 V - 480 V ± 10 %
Current consumption 13 A (400 V)
Open circuit voltage 100 V
Insulation class F (E for multivoltage option)
Protection class
IP 23 (with touchscreen closed)
IP 20 (with touchscreen open)
Weld current range 5 to 300 A
Current regulation ± 1 % if I > 100 A and ± 1 A if I ≤ 100 A
Duty cycle
300 A at 60 %
240 A at 100 %
Pulsed current range
300 A range: 5 to 300 A
Time period from 10 to 3300 ms
Movements monitored
Welding head rotation
Wire feeder
Height of arc - AVC - (option)
Oscillation - OSC- (option)
Speed accuracy
± 1 % at Vp ≥ ¼ V
max
(Vp = programmed speed)
± 2 % at Vp < ¼ V
max
Gas monitored Torch gas, second gas (option)
Source cooling Forced ventilation
Weld torch cooling
Cooling liquid in closed loop with safety device (2nd circuit as
option)
Display of actual magnitudes during cycle
Continuous display of the power source output voltage and
the weld current (if remote control unit or touchscreen option
present)
Number of stored WPs 200 maximum
Sectors per program 99 maximum
Archiving and loading on USB-key
Overall dimensions
630 x 470 x 790 mm (L x D x H)
630 x 470 x 1110 mm (Multivoltage version)
Weight
76 kg
(with cooling liquid, touchscreen and printer)
160 kg in multivoltage version with carrier
Standards EN 60974-1 et EN 60974-10
The EMC classifi cation to EN 55011 (EN 60974-10) has been executed to class A requirements.
The heating tests have been carried out at ambient temperature. The duty cycle at 40 °C has been determined
by simulation.
