Polysoude P6 - Front Panel Controls and Connections; Front Control and Connection Panel Item List

THE ART OF WELDING
P6
44-92 PN-0509076 Rev. 16
Description of controls4. 5.
Front control and connection panel4. 5. 1.
Item Designation
FA 2 Connection of the remote control unit.
FA 3 Connection of the rotation cable.
FA 4 Connection of the wire feeder.
FA 5 Connection of the command cable of a manual torch or of a type MW welding head.
FA 7 Connection of a second gas (option).
FA 9 Connection of the torch gas.
FA 10 Connection of the earth cable.
FA 11 Connection of the torch current cable.
FA 12 Coolant outlet connection 1.
FA 13 Coolant return connection 1.
FA 14 Connection of the PC interface (RJ45).
FA 15 Connection of the USB key.
FA 16
Short press: a ticket is printed summarising the welding carried out.
Long press (> 2 s): print-out of the program selected.
FA 17
Indicator light; on when USB key busy with reading/writing.
Do not remove the USB key
when the light is illumina-
ted.
FA 18 Write command on the USB key.
FA 19 Read command on the USB key.
FA 24 Coolant outlet connection 2.
FA 25 Coolant return connection 2.
FA 26 Connection of workpiece U
arc
cable
FA 27 Connection of AVC and oscillation cable
